Intellectual Property

Intellectual Property, or IP as it is abbreviated, is a very important topic. So what is Intellectual Property?

Intellectual Property

Intellectual Property

The diagram above shows some examples. Here are some more examples of Intellectual Property that specifically apply to the Electronics Design and Embedded Software Development:

  • Patents
  • Copyright
  • Industrial design rights
  • Plant varieties
  • Trademarks
  • Trade dress
  • Trade secrets

Copyright applies to things such as:

  • specification and requirements documents
  • reports
  • source code
  • schematic designs
  • PCB layouts
  • Bills of Materials (BOMs)
  • Product assembly and test instructions
  • source code
  • this blog

So a lot of the value created in a new Product Development project is bound up in the Intellectual Property generated.

Why this is important, is that many individuals and companies that offer Product Development services do not give you Intellectual Property Rights to the product you paid them to develop for you. We have picked up quite a few projects over the years where this lead to a toxic relationship between the client and the developer and they needed to go elsewhere.

Protecting your Intellectual Property

To protect your Intellectual Property the obvious steps are:

  • Have a non-disclosure agreement in place prior to sharing any information with another party
  • Ensure all staff and contractors have signed a non-disclosure agreement
  • Check out patents early. Both to determine if you might be able to patent, and also to make sure you aren’t violating anyone else’s rights.
  • Although Copyright vests automatically in Australia, do use Copyright notices
  • Make everyone clear on what you Intellectual Property Policy is
  • Register designs and trademarks
  • Also purchase relevant domain names

Intellectual Property Policy

A question we are often asked is “What is your Intellectual Property Policy“?

Here is how we handle IP including our own which we can license into your project to save both time and cost:

  • IP developed for you is owned exclusively by you and not used for any other purpose
  • IP provided by you is owned by you and only used for the purpose it was provided for
  • we will not share anybody else’s IP with you without their prior permission
  • we will not share your IP with anyone else without your prior permission
  • the non-exclusive license to our background IP is a single purchase at an agreed price and can be leveraged across multiple products
  • where improvements in our background IP become available, they can be incorporated into your product and only the modification cost applies
  • we regular sign non-disclosure agreements and even have one of our own you can use if you don’t have a suitable one yourself

And the last part is usually about how we charge for all this. The are specific costs associated with generating your exclusive IP for a product. Where variants are then designed, only the adaption or variation cost will be incurred. So for instance, changing from one NB-IoT vendor’s cellular modem to another modem from another vendor will only cost the PCB changes and code modification costs and would be expected to be substantially less cost than the initial implementation.

Another way to put all this, is that if you pay for it, you own it without any encumbrance.

Our aim is to ensure your success so it doesn’t make sense to make it difficult for you to own and exploit your own Intellectual Property.

And a little humour to finish off.

Copyright Humour

Copyright Humour

Successful Endeavours specialise in Electronics Design and Embedded Software Development, focusing on products that are intended to be Made In AustraliaRay Keefe has developed market leading electronics products in Australia for more than 30 years. This post is Copyright © 2017 Successful Endeavours Pty Ltd.

What is a Prototype?

A Prototype is done in order to explore some aspect of a new opportunity without having to fully commit to it yet. Prototype has a number of potential meanings including:

  • the original or model on which something is based or formed.
  • someone or something that serves to illustrate the typical qualities of a class; model; exemplar:
  • something analogous to another thing of a later period:
  • Biology. an archetype; a primitive form regarded as the basis of a group.

So a Prototype is either an early model or a smaller scale development to test a new idea.

Why Prototype?

So for engineering, we Prototype to reduce risk, and we learn from Prototypes to improve the likelihood of project success by being better informed for the next round of design. So a Prototype is a core Product Development Process Risk Management strategy.

Product Development Process

Product Development Process

A Prototype can also reduce other risks such as financial risk or market risk and isn’t always done for technical risk reasons.

Financial risk can be managed by breaking a project up into a series of stages and only committing funds to a stage when its predecessor has been successfully completed. A Prototype is often done ahead of a major block of Product Development to test whether the technical approach is likely to succeed and provide early warning of unexpected problems or interactions.

Market risk can be managed by trialing a new product idea with a smaller group of candidate customers to gauge their acceptance of the product. This has to be well managed however as history has shown that this approach, especially in the case of focus groups, can often just elicit the outcome the company hoped for and not a real example of how the market will react. Just look at all the failed Coca Cola new flavour launches.

And of course, technical risk can be managed by making Prototypes that implement the highest risk features as early as possible. We covered this in Improving Product Development.

A Prototype can often be used during Engineering Analysis in order to evaluate the effectiveness of different options for addressing the Requirements. This is covered in Electronics Design Process.

Successful Endeavours Development Process

Successful Endeavours Development Process

And then having designed a product it is normal to build a Prototype to ensure the final solution works as expected. This manages the risk that production tooling might need rework or even redesign.

How to Prototype?

This depends on the problem you want to solve. For this section we will focus on technical risks. A Prototype is very useful to allow you to measure some essential elements of the final product without committing to a final solution. So you can explore:

  • modelling a problem and simulations
  • noise and interference
  • power consumption
  • performance versus cost (compare several different prototypes)
  • responsiveness
  • system resources required
  • hardware versus software solutions
  • temperature rise
  • materials properties
  • shape and usability / ergonomics
  • fit (especially PCBs in mechanical housings)

And the list can go on. The key is to determine where the risk is and manage that. In Project Management Pre-preparation we looked at using a Prototype to reduce both technical and financial risk at the same time. In this case, other developers hadn’t been able to produce a working product so the client had a clear risk to manage. And our approach was to make a jig that allowed us to explore the sensing that was needed and get real data to then analyse and develop a solution. The same jig allowed the solution to then be tested before we designed the Electronics PCBs and Embedded Software needed for the final product. And the client was able to authorise each next level of expenditure with confidence based on us having delivered against the requirements for the previous stage.

Simulation

Simulation

And of course, 3D Printing for Electronics has enormously expanded the possibilities for mechanical prototypes by allowing anyone to quickly build and test the fit of objects together. It is also a viable option for low volume manufacturing.

3D Printed Spacer

3D Printed Spacer

3D Printed Spacer Fitted

3D Printed Spacer Fitted



Successful Endeavours specialise in Electronics Design and Embedded Software Development, focusing on products that are intended to be Made In AustraliaRay Keefe has developed market leading electronics products in Australia for more than 30 years. This post is Copyright © 2017 Successful Endeavours Pty Ltd.

Powering Telemetry

A big issue in the world of the Internet of Things, or IoT as it is abbreviated, is how to get power to remote devices. And this splits up into 2 separate but definitely related problems:

  • the power source
  • the power consumption

Obviously, if the power consumption is high, the power source has to be capable of providing a lot more power. We looked at this in our IoT – Remote Telemetry Case Study. So let’s tackle that one first.

And the focus for this article is remote devices using Solar Charging. Before we look at that specifically, let’s understand the problem.

Power Consumption

There are multiple ways to reduce power consumption. These were covered already in Reducing Power Consumption and Reduce Power While Awake with examples given in Sleep Saves Energy.

Low Power Sleep Mode

Low Power Sleep Mode

The short version of this is that you have to do 2 things at the same time:

  • reduce the average power that is consumed all the time
  • reduce the energy required to process an event

The first of these is also known as Quiescent Power Consumption. This is the power consumed just running the system when it is doing nothing, or close to it. At a minimum, the Power Supply has to deliver this amount of power just to make sure that we could react to an event, should it occur. And I can hear you thinking that it is hard to get this low enough and still have a responsive system.

Correct! But you have to have at least this amount of power or Game Over!

Which is where the second part comes in. You also need some power to respond to events. These can be something you need to log, or reports you need to post. If you are uploading to a web service using cellular communications, the peak power consumption can be very high. So you have to minimise this time.

We would normally model both of these and work out a power budget based on the worst case scenario model. Excel is a suitable tool for doing simple modelling of this as well as scenario modelling.

But I can hear you thinking “why worst case“? Answer: “Because you want it to always work, not just work on average“!

Telemetry

Telemetry means measurement at a distance or remote measurement. So you are measuring something at location A, and want to know the value of the measurement at location B. This implies the 2 locations are not close enough together that this is a trivial problem to solve.

In our world, Telemetry can mean anywhere on earth, though our customers are usually in Australia. In NASA’s world, (maybe world is the wrong term for them) it can be anywhere in the solar system. Voyager 1 is currently more than 18 billion Kilometers away and has been active for 40 years.

Artist's concept of Voyager in flight

Artist’s concept of Voyager in flight

The challenge for low power consumption, is how to get the measurement from location A back to location B?

Solar Charging

The NASA solution is simple. Near sun facilities are Solar Powered, and the rest use some form of nuclear power. Since no-one will ever let us nuclear power any Telemetry device, and I’m Okay with that, and we are near enough to see some sun, we will follow that option instead. And besides which, we can do it in our office and not a heavily shielded facility.

So lets recap on what we know about solar charging:

  • ignoring the energy cost of making a solar panel, the energy cost is free after that
  • there is a maintenance cost which includes cleaning panels
  • provided the construction is robust, they are a long life product
  • you have to do Maximum Power Point Tracking (MPPT) to harvest the most energy or minimise the panel size

And to get more power from a solar panel, you have to:

  • have more sun
  • have a better angle to the sun (cosine reduction)
  • have a better MPPT
  • handle lower voltages
  • use the right silicon

Not all Solar Panels are equal. If you want you panel to work in a mostly shady place then you might also want to use mono-crystalline Silicon solar cells because they are efficient and can continue to convert even low levels of light. In recent developments the efficiency of conversion had passed 25% as reported in Efficiency of Silicon Solar Cells Climbs and some of the stacked cell technologies are past 40% efficiency.

compact solar cell

compact solar cell

And then you have to harvest that energy. Which is where new devices like the SPV1050 come in. Experiments in our office showed that we can charge a Lithium Polymer battery from the internal lighting. And it is a buck boost converter meaning that it can charge the battery in full sunlight (reducing voltage) and also moonlight (increasing voltage) and the device costs less that $2 in 1K pieces.

I only have on criticism. The super low quiescent current LDOs would have been more useful if they were fully independent because this would have taken another item off the Bill of Materials.

Primary Cells

The other option for Telemetry is using Primary Cells. These are not rechargeable and so must last the life of the product. We currently deploy Cellular based Telemetry modules that can run for up to 10 years from a Lithium Primary Cell or 5 years from Alkaline Primary Cells. This is ideal for Smart City style projects where the devices might be moved as they fulfill their current purpose. A good example of this is people metering or pedestrian counting where a council may want to know how much use an area is getting. Once that is understood, the Telemetry module can be redeployed and since it isn’t connected to mains power you don’t need an electrician to do that. Or they could be used to understand the level of demand of public transport services in real time so you can adjust capacity on the fly.

So there are options and as technologies like NB-IoT and CAT-M1 come online the power budget for cellular communications continues to fall. We covered this in Cellular IoT Communications. And as of last month, Telstra turned on CAT-M1 across the 4GX network.

Quectel BG96 CAT-M1 Module

Quectel BG96 CAT-M1 Module

Successful Endeavours specialise in Electronics Design and Embedded Software Development, focusing on products that are intended to be Made In Australia. Ray Keefe has developed market leading electronics products in Australia for more than 30 years. This post is Copyright © 2017 Successful Endeavours Pty Ltd.

Smart Cities

This follows on from our look at Smart Cities and the technology mix being considered for how you implement them. For this post we will look at the development of a Smart City Telemetry sensor suite and the ICT communications that go with it. This is also a classic IoT case study.

I also want to point out that a Smart World will only happen if we have Smart Regions, Smart Countries, Smart States or Territories, Smart Cities and Smart Neighbourhoods.

arcHUB

My thanks go to The Active Reactor Company for giving me permission to share their story about the development of the arcHUB Telemetry sensor suite which is aimed at the Smart Cities programs as well as being more widely deployable.

arcHub Telemetry Module

arcHub Telemetry Module Logo

A few days ago I had the opportunity to speak with Daniel Mulino who is the State Member for Eastern Victoria. The picture below comes from his visit to our office in Narre Warren. The original post he made along with my explanation is here. I’m giving a more detailed explanation below including some history.

Ray Keefe - arcHUB - Daniel Mulino

Ray Keefe – arcHUB – Daniel Mulino

For those wondering about the device I am holding, it is an arcHUB Smart Cities Telemetry module aimed at Smart Cities projects and environmental monitoring where you don’t have access to, or want the cost of, connecting up mains power. This is designed for The Active Reactor Company and is already involved in 1 Smart Cities deployment and multiple trials of low cost sensor modules by councils and government agencies in 3 states. I can’t yet provide specific details on those as they are covered by non-disclosure agreements.

To understand how we got here, it helps to know the history.

The Active Reactor Company make a product called The Active Reactor. It improves both the efficiency and the life of arc lamps such as low pressure sodium street lights, high pressure Sodium  and metal halide lamps.

The Active Reactor

The Active Reactor

With the advent of LED street lighting their current product is not needed for new installations and so they wanted to secure the future of the business. So a great example of addressing an issue that will arise in the future so you are ready for it rather than just reacting to it once it happens.

Initially the new product was aimed at monitoring LED street lights. One of the big issues with LED lighting is that the LEDs either fail over time or they fade and lose brightness. Or a mixture of both. The fading is a result thermal diffusion in the semiconductor substrate. When they fall by more than 30% then you have to address that as they no longer comply with legal standards for lighting levels. The other catch is that the claimed life of 10+ years isn’t yet proven and so it is expected that there will be many lights that fail early or fade early or both.

Of course, once you have a communicating device that can monitor one thing and report it, it can also monitor other things and report them as well. Plus there were issues with being allowed to monitor the light. And where would the power come? Their inquiries with authorities responsible for the poles would not give permission to tap the power in the pole or light.

So this set us the follow set of constraints to work within:

  • must be battery operated
  • easy to install
  • low cost to make and also run
  • communicate using the cheapest data transport
  • monitor the LED light at night and keep track of the brightness trend
  • send an alert when it is persistently out of specification
  • field life to match the street light (10+ years)

As The Active Reactor Company talked to target users (initially the same people who buy their current product) and got an idea of what they wanted, a very different picture emerged. The people who cared about LED street lighting, also cared about micro climates, and soil moisture levels, and air quality, and foot traffic, and …

So that lead to a change of direction and a look at what else was required. The result is a device aimed at the Smart Cities market that also suits a wide range of other end customers and has the following features you won’t find combined together in conventional devices:

  • battery operated (either solar charged or primary cells)
  • minimum 2 year battery life for standard AA cell alkaline batteries
  • 10+ day running time if solar charging is lost
  • up to 20 days on board non-volatile storage
  • compact form factor
  • multiple sensor types per node (up to 20)
  • sensor area network to minimise data costs
  • over the air firmware upgrades
  • over the air configuration updates
  • variable sample rates and upload timing
  • still has to be low cost to make and also run
  • easy to install

So here is the range of sensors already trialed:

  • wind speed (external anemometer attached)
  • sunlight level
  • night light level (street light monitoring etc)
  • temperature
  • PM2.5 particulate levels
  • PM10 particulate levels
  • Gasses – CO, H2S, SO2, NO2, H2S
  • Humidity
  • People counting (PIR based anonymous counting)
  • Soil moisture levels (external probe)

It is also the HUB and coordinator of a Sensor Area Network that can include modules that can measure any of the above as well as:

  • vibration
  • shock
  • movement
  • water level
  • GPS location
  • USB charger current (for usage analysis)
  • counting any device or system that has a pulse output
  • analog voltage measurements (AC and DC)
arcHUB trial at Fitzroy Gardens

arcHUB trial at Fitzroy Gardens

The arcHUB is solar powered and includes a cellular modem to allow reporting back to a web service. It is designed to mount to a pole using straps but can easily be mounted to a wall or any other typical structure. A typical scenario is measurements every 15 minutes (except people or pulse counting which are continuous) and uploading to the web service every hour.

With the release of CAT-M1 services across Australia by Telstra, we are expecting migrate to this communications standard because it will reduce power consumption by at least a factor of 4 which will further improve battery life.

Quectel BG96 CAT-M1 Module

Quectel BG96 CAT-M1 Module

The arcHUB Peripheral Modules connect via 915MHz ISM Band communications and use standard AA batteries. They can run for between 2 and 5 years depending on what sensors are attached and how often they are read and reported. If you used primary lithium cells then you can expect life beyond 10 years.

The arcHUB Peripheral Modules are also capable of stand alone operation with the addition of an internally fitted cellular modem so you can have a portable people counter module that can be easily moved to a new location and doesn’t require an electrician to install it.

And pretty exciting to also announce that this is not only a designed in Australia product range, but it is also a made in Australia product range.

Again, my thanks to The Active Reactor Company for permission to share this story and if you want to know more, leave a comment and I will put you in touch with them.

Successful Endeavours specialise in Electronics Design and Embedded Software Development, focusing on products that are intended to be Made In AustraliaRay Keefe has developed market leading electronics products in Australia for more than 30 years. This post is Copyright © 2017 Successful Endeavours Pty Ltd.

Printed Electronics

Way back in 2011 we looked at the state of Printed Electronics and concluded this was a rapidly emerging area of Technology and had been since the previous look at The Future of Low Cost Electronics Manufacture in 2009. It has been a while so what has happened since then?

Printed Electronics

Printed Electronics

This is another guest post by Andrew Walla.

Andrew Walla

Andrew Walla

Printed Electronics Overview

Rapid prototyping, also referred to as 3D printing or additive manufacturing is the process of building objects or devices by building up layer by layer [1]. It has been identified as a potentially disruptive technology in the manufacturing industry in the coming years and is particularly well suited to provide benefits to technologies that operate on smaller scales of production [2]. New manufacturing paradigms, such as direct manufacturing (directly printing the sold goods) and home manufacturing (providing the capability for consumers to produce parts themselves) are set to change the way that small manufacturing businesses operate and significantly increase the level of competition in the industry [3].

This post will discuss the manufacturing technique of printing – a technology whose origins date back more than five centuries [4] and in this time a number of different printing methods have been developed. Successive layers are generally printed onto a substrate either by direct contact; via an impression cylinder (such as in flexographic, graviture or offset printing), deposited via a stencil (screen printing); or directly deposited onto the substrate (for example, inkjet printing, aerosol-jet printing or organic vapor-jet printing). Of these technologies, inkjet printing is particularly well suited to rapid prototyping and low volume manufacturing due to its high customisability, relatively high resolution and relatively low set-up cost [1].

Inkjet printed electronics differs to conventional inkjet printing in that the deposited substances need to exhibit desired electronic behaviours. A common method to achieve this is to intersperse the ink (a solvent) with nano-particles (small particles with controlled sizes, typically in the order of nano-meters) with desired conductive, dielectric or semiconducting characteristics. The printed substance might be treated post printing in order to evaporate the solvent and/or facilitate a chemical change in the nano-particles. Examples of such treatment include thermal curing [5], curing by ultraviolet light [6], laser sintering [7], e-beam sintering [8], chemical sintering [9] or plasma sintering [10].

Current research efforts are focusing on improving the printing and post-processing technologies available [10-12], improved interconnects [13] and vias [14], improved semiconductors, and printing under less stringent conditions. Examples include printing conductors at room temperature [6] and printing elements such as transistors [15] and diodes [16] with ever increasing performance characteristics. It is forecast that these improvements will continue for some time, as the fastest known inkjet printed transistor has an operating speed of around 20MHz [17-18]. (This is several orders of magnitude behind the capability of existing silicon chip technology.) Researchers are also working on developing transistor characteristics other than maximum frequency. For example, inkjet printing technology has been used to produce flexible and transparent transistors [19].

For those looking to predict where printed electronics will have the greatest future impact, it may pay to think outside the box. In the authour’s opinion, inkjet printing technology is likely to play a larger role in enabling new applications than it is to replace existing electronic technology. It is unlikely that a device with the functionality of a smartphone will be printed anytime soon, but perhaps the capability of printing your own solar panels is closer than you think.

[1] N. Saengchairat, T. Tran and C.-K. Chua, “A review: additive manufacturing for active electronic components,” Virtual and Physical Prototyping, vol. 12, no. 1, pp. 31-46, 2017.
[2] A. O. Laplume, B. Petersen and J. M. Pearce, “Global value chains from a 3D printing perspective,” Journal of International Business Studies, vol. 47, pp. 595-609, 2016.
[3] T. Rayna and L. Striukova, “From rapid prototyping to home fabrication: How 3D printing is changing business model innovation,” Technological Forecasting & Social Change, vol. 102, pp. 214-224, 2016.
[4] S. H. Steinberg, Five hundred years of printing, Maryland: Courier Dover Publications, 2017.
[5] N. Graddage, T.-Y. Chu, H. Ding, C. Py, A. Dadvand and Y. Tao, “Inkjet printed thin and uniform dielectrics for capacitors and organic thin film transistors enabled by the coffee ring effect,” Organic Electronics, vol. 29, pp. 114-119, 2016.
[6] G. McKerricher, M. Vaseem and A. Shamim, “Fully inkjet-printed microwave passive electronics,” Microsystems & Nanoengineering, vol. 3, p. 16075, 2017.
[7] S. H. Ko, H. Pan, C. P. Grigoropoulos, C. K. Luscombe, J. M. J. Fréchet and D. Poulikakos, “All-inkjet-printed flexible electronics fabrication on a polymer substrate by low-temperature high-resolution selective laser sintering of metal nanoparticles,” Nanotechnology, vol. 18, pp. 1-8, 2007.
[8] Y. Farraj, M. Bielmann and S. Magdassi, “Inkjet printing and rapid ebeam sintering enable formation of highly conductive patterns in roll to roll process,” The Royal Society of Chemistry, vol. 7, pp. 15463-15467, 2017.
[9] S. Wunscher, R. Abbel, J. Perelaer and U. S. Schubert, “Progress of alternative sintering approaches of inkjet-printed metal inks and their application for manufacturing of flexible electronic devices,” Journal of Materials Chemistry C, pp. 10232-10261, 2014.
[10] Y.-T. Kwon, Y.-I. Lee, S. Kin, K.-J. Lee and Y.-H. Choa, “Full densification of inkjet-printed copper conductive tracks on a flexible substrate utilizing a hydrogen plasma sintering,” Applied Surface Science, vol. 396, pp. 1239-1244, 2017.
[11] J.-J. Chen, G.-Q. Lin, Y. Wang, E. Sowade, R. R. Baumann and Z.-S. Feng, “Fabrication of conductive copper patterns using reactive inkjet printing followed by two-step electroless plating,” Applied Surface Science, vol. 396, pp. 202-207, 2017.
[12] H. Ning, R. Tao, Z. Fang, W. Cai, J. Chen, Y. Zhou, Z. Zhu, Z. Zeng, R. Yao, M. Xu, L. Wang, L. Lan and J. Peng, “Direct patterning of silver electrodes with 2.4 lm channel length,” Journal of Colloid and Interface Science, vol. 487, pp. 68-72, 2017.
[13] T. Ye, L. Jun, L. Kun, W. Hu, C. Ping, D. Ya-Hui, C. Zheng, L. Yun-Fei, W. Hao-Ran and D. Yu, “Inkjet-printed Ag grid combined with Ag nanowires to form a transparent hybrid electrode for organic electronics,” Organic Electronics, vol. 41, pp. 179-185, 2017.
[14] T.-H. Yang, Z.-L. Guo, Y.-M. Fu, Y.-T. Cheng, Y.-F. Song and P.-W. Wu, “A low temperature inkjet printing and filling process for low resistive silver TSV fabrication in a SU-8 substrate,” 30th IEEE International conference in Micro Electro Mechanical Systems (MEMS), 2017.
[15] J. Roh, H. Kim, M. Park, J. Kwak and C. Lee, “Improved electron injection in all-solution-processed n-type organic field-effect transistors with an inkjet-printed ZnO electron injection layer,” Applied Surface Science, vol. 420, pp. 100-104, 2017.
[16] K. Y. Mitra, C. Sternkiker, C. Martínez-Domingo, E. Sowade, E. Ramon, J. Carrabina, H. L. Comes and R. R. Baumann, “Inkjet printed metal insulator semiconductors (MIS) diodes for organic and flexible electronic application,” Flexible and Printed Electronics, vol. 2, no. 1, p. 015003, 2017.
[17] X. Guo, Y. Xu, S. Ogier, T. N. Ng, M. Caironi, A. Perinot, L. Li, J. Zhao, W. Tang, R. A. Sporea, A. Nejim, J. Carrabina, P. Cain and F. Yan, “Current Status and Opportunities of Organic Thin-Film Transistor Technologies,” IEEE Transactions on Electron Devices, vol. 54, no. 5, pp. 1906-1921, 2017.
[18] A. Perinot, P. Kshisagar, M. A. Malfindi, P. P. Pompa, R. Fiammengo and M. Caironi, “Direct-written polymer field-effect transistors operating at 20MHz,” Scientific Reports, vol. 6, pp. 1-9, 2016.
[19] L. Basiricò, P. Cosseddu, B. Faboni and A. Bonfiglio, “Inkjet printing of transparent, flexible, organic transistors,” Thin Solid Films, vol. 520, pp. 1291-1294, 2011.





Andrew Walla, RF Engineer, Successful Endeavours

So there has been some substantial change but we aren’t yet at the point where this type of Electronics Design and Manufacture has begun to significantly disrupt the mainstream industry. But I can imagine the day when some of what I do now can be printed and tested right now on my desk instead of having to go through PCB Design, PCB Manufacture and Electronics Prototyping first. Can’t wait for Printed Electronics to become mainstream.

Successful Endeavours specialise in Electronics Design and Embedded Software Development, focusing on products that are intended to be Made In Australia. Ray Keefe has developed market leading electronics products in Australia for more than 30 years. This post is Copyright © 2017 Successful Endeavours Pty Ltd.





Power Supply Specification

The idea for this post came from a discussion in IEEE Collabratec on how to design a Power Supply. The question of how to design a Power Supply seems innocuous enough until you really start to think back on past Power Supply designs. I was originally concerned that this was a student wanting someone else to do their coursework assignment for them but the discussion progressed into something quite useful. Here is what I posted after getting the following specification:

  • Output Voltage: -300VDC
  • Output current: 0.5-20mA
  • Tolerance: 30Volts
  • Input Voltage: 220-240 AC
Power Supply

Power Supply

Analysing Requirements

Hi …

is this project part of your course work?

The reason for this question is that the intent of coursework is to help you come to grips with what you are being taught and learn it from a practical perspective as well. Among other things, this helps a lot with retention.

I run a company that designs products for other people. I only employ graduate engineers who have demonstrated the capacity (though their academic results) and inclination (through their having done their own projects and learned how to use the teaching they have received) to do engineering and to be capable of quickly learning all the things they can’t teach in a course.

So if it is coursework, what subject is it part of?

Because if they want you to design a switching mode power supply, that is very different to an AC rectified transformer design.

You also need to be careful with a design assignment like this (coursework or a product that will be manufactured) because it is capable of killing you if you don’t use good safety practices.

I’ll assume your tolerance figure is +/-30V = +/-10% of -300VDC. So the voltage at its maximum excursion from 0V could be -330. And the maximum current is 20mA. This is 6.6W of power so it will get hot. And again, there is enough voltage to kill you.

If it is for a commercial product, then there are usually other constraints. Here are some of the questions I would be asking:

  • The input voltage range is specified as 220VAC to 240VAC but it is normal to allow for short term transients. So does the output voltage have to be clamped during mains transients?
  • Is soft start required?
  • How quickly must it respond to load transients?
  • What is the load and how much does it vary?
  • Does the input stage need to be designed so that it keeps harmonics and power factor under control (this is a legal requirement for some product types)?
  • Is there a maximum size?
  • What is the design life and/or MTBF (Mean Time Between Failure)?
  • Is fan forced convection allowed, and if so, is that even a good idea because of the MTBF or because it goes inside a sealed cabinet)?
  • What is the maximum temperature rise allowed on any of the outside surfaces?
  • What type of connections for the input and output voltages?
  • What has to happen if the output goes short circuit or open circuit (you had a minimum current of 0.5mA so is there a minimum external load and what is allowed to happen if that isn’t there)?
  • What is the environmental specification (0->70C, -20->85C, -40->85C etc)?
  • Is there a manufactured cost target?
  • Do you have to simulate it only, or are you building one and proving the performance?
  • Are there any special safety or EMC compliance requirements for this application?

And there are lots of other questions like this for a real product design.

So regardless of the reason for the design, understanding the intent of the exercise is important to delivering a satisfactory outcome.
This is one of the reasons engineering is not easy. We create the future. Others say that as well. But we also create the infrastructure and products that make a more advance future possible. And there are always lots of constraints.

I hope that has maybe encouraged you to think a bit deeper about the question. It is unlikely you will solve a problem you don’t fully understand. And an answer you don’t work through for yourself will probably not expand you understanding.

Successful Endeavours specialise in Electronics Design and Embedded Software Development, focusing on products that are intended to be Made In Australia. Ray Keefe has developed market leading electronics products in Australia for more than 30 years. This post is Copyright © 2017 Successful Endeavours Pty Ltd.

We Won Best Networking Implementation

You might have read our post on being finalists at the PACE Zenith Awards 2016. Tonight we won the Best Networking Implementation award for 2016. Our Congratulations also go to IND Technology. Their Early Fault Detection product was the design we won this award for.

PACE Zenith Winners 2016

PACE Zenith Winners 2016

If you are wondering what the product does, it measures electromagnetic radiation from the electricity distribution grid using custom designed antennas, does DSP math on it, determines if a fault condition such as Partial Discharge is present, and sends an alert if it detects that. It does this at 250MSPS every second and uploads the summary results to a web service. Using PPS GPS synchronisation you can determine the distance to the fault from each EFD Device. Scatter a few of these around the network and you have the most cost effective Early Fault Detection system you can get. It is also a classic high bandwidth IoT project.

OK, enough engineer speak. Here is a summary from the night.

The MC was Merv Hughes who brought a lot of humour to the night through his novel pronunciation of technical terms.

The Keynote Address was given by Dr. David Nayagam who walked us through the The Bionic Eye project and the difference it was going to make to people experiencing blindness that didn;t have underlying receptor damage.

And we had an extraordinary interlude of entertainment by the Unusualist, Raymond Crowe.

PACE Zenith Awards 2015

PACE Zenith Awards 2016

2016 PACE Zenith Awards Winners

Here are all the winners by category:

  • Safety system innovation – Robotic Automation, for Multi-product Robotic Automation
  • Manufacturing Control – Sage Automation, for Integrated Process Control
  • Automation Innovation – Robotic Automation, for Multi-product Robotic Automation
  • Transport Control – Encroaching. For POW’R-LOCK
  • Mining and Minerals Process Control – Scott Automation & Robotics, for ROBOFUEL
  • Water and Wastewater Control – SMC, for Ethercat Network for Treatment of Wastewater
  • Machine Builder – Automation Innovation
  • Oil and Gas Innovation – Yokogawar Australia, Julimar Development Project
  • Power and Energy Management – Alliance Automation, Oxley Creek Rehabilitation Project
  • Best PLC. HMI and Sensor Product – Bestech Australia, Beanair Wireless Sensor Network
  • Best Network Implementation – Successful Endeavours, IND Technology Early Fault Detection System
  • Young Achiever of the Year – Kayla Saggers
  • Lifetime Achievement – Peter Maasepp
  • Project of the Year – Yokogawa, Julimar Development Project

Our congratulations go to all the participants.

Successful Endeavours specialise in Electronics Design and Embedded Software Development, focusing on products that are intended to be Made In Australia. Ray Keefe has developed market leading electronics products in Australia for more than 30 years. This post is Copyright © 2016 Successful Endeavours Pty Ltd.

IoT Electronics

The Internet of things, or IoT, is driving semiconductor manufacturing at a faster rate than any previous technological revolution. Just last year the 2020 IoT Economy was estimated at $1T. This year, it has doubled to $2T. Here are some facts I’ve gathered about this industry.

  • 2014 – $180B in revenue
  • Today – more machines online than people
  • 2020 – $2T in revenue (eg. > Aus GDP Today)
  • Affects every economic sector
  • Peak growth year is projected to be 2016
  • Largest growth industry in history
  • Compound growth > 15% per annum

Why I am interested is that we design products that fit this category, and like any business owner, I want to understand where the market is going and what new opportunities I should be taking advantage of. As an electronics engineer I am interested in the technology itself and what design skills are needed to work with it.

It has become so important it has its own term, IoT Economy.

According to BI Intelligence IoT Report, within 2 years the number of new electronics devices manufactured for the Internet of Things will exceed all other sectors combined!

IoT Growth Projections graph

IoT Growth Projections

 IoT  Growth

So we are looking at the fastest economic growth trend ever for electronics. And there are several good reasons for this:

  • It is an essential enabling technology for Industry 4.0
  • Semiconductor device unit cost has been falling for decades
  • Processor computational power has been rising
  • Communications cost is falling
  • Power consumption is falling

This combination allows low cost, low power, communicating devices to be everywhere. In just 1 year, the projected growth doubled from $1T in 2020 to $2T in 2020.

Electronics Design for the IoT

I’ve shown an example of one driving force for IoT Growth and that is low power IoT Remote Telemetry. The Electronics Design required for this is something we are now doing every single day. Of the 20 projects we are working on right now, half of them are for the Internet of Things. In the photograph below which was taken for some for some PR for the City of Casey, every single award was for design of a device or the web services needed to support devices for the Internet of Things.

IoT Awards Successful Endveavours - Internet of Things

IoT Awards Successful Endveavours

Above you can see some of our team. The certificates they are holding are from the past 14 weeks starting with the National Manufacturing Week Endeavour Awards from the end of May.  So this is also our biggest growth area.

Successful Endeavours specialise in Electronics Design and Embedded Software Development. Ray Keefe has developed market leading electronics products in Australia for nearly 30 years. This post is Copyright © 2015 Successful Endeavours Pty Ltd.

Product Development

As a process, Product Development can be handled a number of different ways. And if your product only requires input from a single technical discipline which you are very experienced in, then you can usually predict everything you need to do and just make sure it all happens the right way.

But if the product is complex, involves many disciplines, and has unknowns about the technical direction to take, then it can sometimes resemble a roller coaster ride more than it does a straight forward journey. And there can be unexpected bumps along the way.

Our most recent employee brought this video to my attention and I thought it covered this topic really well. We used it for an in house lunch and learn session so I recommend you check it out to. It isn’t short so you might want to set aside a time you can sit back and enjoy it.

The presented is Andrew “Bunnie” Huang and the conference he is presenting at is linux.conf.au 2013.

Quite a list of things you can run into just getting a fully package embedded computing device ready for market. The HDMI Man In The Middle exploit was my favourite part.

Successful Endeavours specialise in Electronics Design and Embedded Software Development. Ray Keefe has developed market leading electronics products in Australia for nearly 30 years. This post is Copyright © 2015 Successful Endeavours Pty Ltd.

PACE Zenith Awards

The PACE Zenith Awards 2015 celebrate the process control and automation industry’s many and diverse successes. The PACE Zenith Awards bring together some of the biggest names in Process Control, Instrumentation and Automation to celebrate, recognise and award companies and individuals for their key contribution to Australian industry.

The awards winners were announced at the PACE Zenith Awards dinner at the Four Seasons Hotel Sydney on June 11th 2015.

This year we were finalists in 4 categories with the Power and Energy Management category having 2 projects selected as finalists.

Successful Endeavours Finalists PACE ZENITH 2015

Successful Endeavours Finalists PACE ZENITH 2015

The categories we were finalists in were:

  • Water and Wastewater – for our IoT Monitoring Platform + Telemetry Host
  • Best Fieldbus Implementation – for our IoT Monitoring PlatformTelemetry Host
  • Power and Energy Management – for our IoT Monitoring Platform  + Telemetry Host and the ABB CQ930
  • Transport Power and Infrastructure – for the ABB CQ930
PACE Zenith Awards - 5 Finalist Certificates - Successful Endeavours 2015

PACE Zenith Awards – 5 Finalist Certificates – Successful Endeavours 2015



PACE Zenith Awards 2015 Winners

So we didn’t win a category, but it was a great night and I always enjoy being part of celebrating what is good in Australian Manufacturing. The winners on the night were:

  • BEST FIELDBUS IMPLEMENTATION = Sigma NSW
  • FOOD AND BEVERAGE = B.-d.Farm Paris Creek
  • MACHINE BUILDER  = H.I.Fraser
  • MANUFACTURING = ANCA
  • MINING AND MINERALS PROCESSING = Sigma NSW
  • OIL AND GAS = H.I.Fraser
  • POWER AND ENERGY MANAGEMENT = Mescada
  • TRANSPORT, POWER AND INFRASTRUCTURE = Sage Automation
  • WATER AND WASTEWATER = Sage Automation
  • YOUNG ACHIEVER AWARD = Aaron Deal, Honeywell Process Solutions
  • PROJECT OF THE YEAR = H.I.Fraser



PACE Zenith Awards 2015

This was our first time at these awards so we learnt a lot about the process and hope to be back next year.

Successful Endeavours specialise in Electronics Design and Embedded Software Development. Ray Keefe has developed market leading electronics products in Australia for nearly 30 years. This post is Copyright © 2015 Successful Endeavours Pty Ltd.

Next Page »
